Compliance to EN61000-4-2,3,4,6,8, EN55024, light industry level, criteria A
OTHERS
DIMENSION
78*51*28mm (L*W*H)
PACKING
0.18kg,60 PCS/11.8kg
测试条件与备注4
All parameters NOT specially mentioned are measured at normal input, rated load and 25℃ of ambient temperature.
Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
Tolerance : includes set up tolerance, line regulation and load regulation.
The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on http://www.meanwell.com)
