- 安全规范
- UL1012, CAN/CSA-C22.2 No. 107.1-01, UL8750(type”HL”), CSA C22.2 No. 250.0-08; BS EN/EN/AS/NZS 61347-1, BS EN/EN/AS/NZS 61347-2-13 independent(除 HLG-240H C 型外); IEC/UL/BS EN/EN 62368-1(except for AB,D type), UL8750;GB/T19510.1,GB/T19510.213(除 C 型外); IP65或IP67;J61347-1,J61347-2-13(除C, D型外), BIS IS15885(仅48V),EAC TP TC 004,KC61347-1,KC61347-2-13(除AB,C,D型外) 认证通过
- 耐压
- I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC
- 绝缘阻抗
- I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
- 电磁兼容发射
- 符合BS EN/EN55015, BS EN/EN55032 (CISPR32) Class B,BS EN/EN61000-3-2 Class C (@负载≧50%); BS EN/EN61000-3-3,GB/T 17743,GB17625.1,EAC TP TC 020;KC KN15,KN61547(除AB,C,D型外)
- 电磁兼容抗扰度
- 符合BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN61547, BS EN/EN55024,轻工业标准(浪涌抗扰度: 线对地4KV,线对线:2KV),EAC TP TC 020;KC KN15,KN61547(除AB,C,D型外)
