APV-8E-12 · 牌恒压输出防水塑壳LED照明电源

APV-8E series is one 8W AC/DC constant voltage mode single output LED power supply. It accepts input 180~264VAC and provides three models with different output voltage, 5V, 12V, 24V, respectively, that the small wattage LED applications employ the most frequently. Exploiting Class II design (without FG pin) and adopting the 94V-0 flame retardant plastic enclosure, APV-8E ideally fits the entry-level LED applications.

产品特点

• Constant voltage design
• Class Ⅱ power unit, no FG
• Fully isolated plastic case
• IP42 design
• Small and compact size
• Cooling by free air convection
• Protections: Short circuit / Overload / Over voltage
• No load power consumption <0.5W
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty
