- OUTPUT NUMBER
- CH1 CH2 CH3
- DC VOLTAGE
- CH1: 3.3V CH2: 5V CH3: 12V
- RATED CURRENT
- CH1: 10A CH2: 8A CH3: 0.5A
- CURRENT RANGE (convection)
- CH1: 1 ~ 10A CH2: 0.8 ~ 8A CH3: 0.05 ~ 0.5A
- CURRENT RANGE (18CFM FAN)
- CH1: 1 ~ 12.5A CH2: 0.8 ~ 10A CH3: 0.05 ~ 0.63A
- RATED POWER (convection)
- 79W
- RATED POWER (18CFM FAN)
- 98.81W
- RIPPLE & NOISE (max.)注Note.2
- CH1: 100mVp-p CH2: 100mVp-p CH3: 120mVp-p
- VOLTAGE ADJ. RANGE
- CH1:3.13 ~ 3.46V
- VOLTAGE TOLERANCE注Note.3
- CH1: ±3.0% CH2: ±5.0% CH3: ±6.0%
- LINE REGULATION
- CH1: ±0.5% CH2: ±0.5% CH3: ±0.5%
- LOAD REGULATION
- CH1: ±3.0% CH2: ±3.0% CH3: ±5.0%
- SETUP, RISE TIME
- 1000ms, 30ms/230VAC 2000ms, 30ms/115VAC at full load
- HOLD UP TIME (Typ.)
- 24ms/230VAC 24ms/115VAC at full load
