PLM-25E-700 · 18~ 700mA 输出IP30 防水塑壳PFC压线端子接线LED恒流电源

PLM-25 is a 25W economical AC/DC LED power supply series. Incorporating a built-in active PFC design, PLM-25 provides a high Power Factor value greater than 0.9. In addition, with the low no load power consumption below 0.5W, and the setup time less than 500ms, PLM-25 is complied with the ErP regulation required by European Union for lighting fixtures. PLM-25 is a class Ⅱ(without FG pin) power unit housed with the UL 94V-0 rated flame retardant plastic case. The I/O terminals are designed with screw-less clamp style terminal block that greatly simplifies the wiring installation. Two types of models with different input voltage range are offered: PLM-25 series, which operates from 110~295VAC, and PLM-25E series, which operates from 180~295VAC.These two series are both constant current output design, supplying models with the current of 350mA, 500mA, 700mA and 1050mA, respectively.

产品特点

• 230VAC only or Full range (up to 295VAC) models available
• Built-in active PFC function
• Constant current design
• Protections:Short circuit
• Cooling by free air convection
• Fully isolated plastic case
• Class Ⅱ power unit, no FG
• Class 2 power unit(for PLM-25-500/700/1050)
• No load power consumption <0.5W
• High reliability,low cost
• 2 years warranty
