GSM18E18-P1J · 高能效医疗型欧规墙插电源适配器

GSM18E is a highly reliable, 18W single-output green medical adaptor series. This product is equipped with a 2-pin (no FG) standard European power plug, adopting the input range from 80VAC to 264VAC. The entire series supplies different output voltages between 5VDC and 48VDC that can satisfy the demands for various kinds of miniature medical devices. The circuitry design meets the international medical standards (2×MOPP), having an ultra low leakage current (<50μA), fitting the medical devices in direct electrical contact with the patients. With the efficiency up to 88% and the extreme low no-load power consumption below 0.1W, the design of GSM06E observes the latest energy regulation (level V); the supreme feature allows the adaptor to save the energy when it is either under the operating mode or the standby mode. The entire series utilizes the 94V-0 flame retardant plastic case, providing the double insulation that effectively prevents electrical shock. GSM06E is approved with the international medical safety certificates.

产品特点

• Universal AC input / Full range
• 2 pole EURO plug
• High efficiency up to 88%
• Low leakage current <50μA
• Protections: Short circuit / Overload / Over voltage
• Fully enclosed plastic case
• Medical safety approved (2×MOPP between primary to secondary)
• Class II power (without earth pin)
• LED indicator for power on
• No load power consumption<0.1W
• ErP step2 compliant (level V)
• Meet EISA 2007 (Energy Independence and Security Act)
• Optional lock type DC plug
• 3 years warranty
